High Density Fiber Panel 288F 2U Unloaded

Partcode: 66011-2000

Description: High Density Fiber Panel 288F 2U Unloaded

3C3® High Density Panel is specially designed to accommodate high density cabling in high end Data Center and Telecommunication central office environment. The shallow depth of High Density Panel makes it suitable for low depth copper racking systems or Telecommunication ODFs. The 2U 19” 288 fiber MPO Panel contains factory controlled and tested Modules can be installed in it. Different types of cassettes are available to deliver optimum Performance and reliability. Integrated fiber management features are provided to secure trunk cables, separate patch cords and maintain safe bend radius during fiber routing.

Features

  • Complies to IEC61754-7, ANSI/TIA-604-5 FOCIS 5, ANSI/TIA 472.AAAD and ISO/IEC 11801
  • Patch Panel design rail and easy pullout.
  • Easy installation: Cassettes can be installed
  • 2U patch panel capacity come up to 288F fully loaded with 24 modules
  • Factory pre-terminated and tested modules are available
  • 19‘’ rack mount, the panel is made of cold rolled steel sheet and module is made of plastic

Specifications

Body Material: SPCC (Cold rolled steel sheet)

Capacity: 288 LC , 288 Splicing, 144 MPO/MTP

Operation Temperature: -40°C~+75°C

Storage Temperature: -40°C~+75°C
